industrial gas sub tank
product description:
industrial gas sub master tank refers to the storage tank in which multiple sub tanks containing ln2, lo2 and lar are connected in parallel and placed in the master tank filled with thermal insulation materials according to a certain arrangement. it is more suitable for the output of air separation unit or the backup system of steel plant to store liquid oxygen, liquid nitrogen, liquid argon and other products respectively, but the site is limited and the land occupation needs to be reduced as much as possible.
product structure:
the cryogenic liquid sub master tank is composed of multiple sub tanks, one master tank, corresponding process pipelines, valves, instruments, etc.
sub tank: as the main container containing low-temperature medium, it is made of austenitic stainless steel s30408; the sub tank is a vertical cylindrical leg structure. according to the volume, 4, 7 or 10 sub tanks are arranged in a certain way to connect the gas and liquid phases of all or grouped sub tanks through pipelines.
mother tank: as the protective shell of thermal insulation system, q345r / 16mndr material is usually used. the mother tank contains all the sub tanks, and uses powder stacking insulation for cold insulation to ensure that the storage medium is gasified as little as possible.
main technical parameters:
storage media: ln2, lo2, lar, etc
working pressure: 0.2mpa ~ 3.0mpa
single volume: 600m ³~ 3000m ³
equipment type: storage tank, pressure vessel
main advantages:
the single storage capacity of the equipment is large, which has the advantages of small land occupation, less investment and simple operation compared with the vacuum tank with the same volume.
the equipment maintains the operating pressure through the self supercharger, does not need the booster pump, has the advantages of fast response time, low operation cost and simple maintenance.
